Cisco AIR-AP1562I-D-K9 – Outdoor Rugged Access Point (Integrated Antenna, Dual-Band)

Cisco AIR-AP1562I-D-K9 – Outdoor Rugged Access Point (Integrated Antenna, Dual-Band)

Cisco AIR-AP1562I-D-K9 is a rugged outdoor 802.11ac Wave 2 access point with integrated dual-band antennas and speeds up to 1.3 Gbps. Built for harsh environments, it supports PoE+, Gigabit Ethernet, and SFP connectivity, making it ideal for campus and outdoor enterprise networks.

4-Year Warranty | 30 Day Returns | 30 Day Exchange

Product Specification

Specification Details
Product Code AIR-AP1562I-D-K9
Type 802.11ac Wave 2 (Wi-Fi 5)
Radio/MIMO 3×3:3 MU-MIMO, up to three spatial streams
Max PHY Rate Up to 1.3 Gbps (80 MHz channel)
Integrated Antenna Dual-band 3 dBi gain (2.4 GHz), 5 dBi gain (5 GHz)
Ethernet Ports 1× 10/100/1000 PoE-in RJ-45
SFP Port 1× SFP (fiber or electrical)
Management Port 1× RJ-45 console
Power Options PoE+ (802.3at/UPoE), DC pass-through, Cisco outdoor PoE injectors
Operating Temperature –40 °C to +65 °C (–40 °C to +55 °C with solar loading)
Wind Survivability 100 mph (sustained); 165 mph (gusts)
Ingress Protection IP67-rated, sealed for outdoor environments
Dimensions (L×W×H) 229 × 173 × 98 mm (9.0″ × 6.8″ × 3.9″)
Weight 2.5 kg (5.6 lb)
Typical Power Consumption ~32 W (when fully powered and active.
Product CodeAIR-AP1562I-D-K9
Antenna Type802.11ac Wave 2 (Wi-Fi 5)
Dimensions (Length x Width)229 × 173 × 98 mm (9.0″ × 6.8″ × 3.9″)
Weight2.5 kg (5.6 lb)
Operating Temperature–40 °C to +65 °C (–40 °C to +55 °C with solar loading)
Wind Survival100 mph (sustained); 165 mph (gusts)
Radio/MIMO3×3:3 MU-MIMO, up to three spatial streams
Max PHY RateUp to 1.3 Gbps (80 MHz channel)
Integrated AntennaDual-band 3 dBi gain (2.4 GHz), 5 dBi gain (5 GHz)
Ethernet Ports1× 10/100/1000 PoE-in RJ-45
SFP Port1× SFP (fiber or electrical)
Management Port1× RJ-45 console
Power OptionsPoE+ (802.3at/UPoE), DC pass-through, Cisco outdoor PoE injectors
Ingress ProtectionIP67-rated, sealed for outdoor environments
Typical Power Consumption~32 W (when fully powered and active.
6. Cisco AIR-AP1562I-D-K9 – Outdoor Rugged Access Point
Cisco AIR-AP1562I-D-K9 – Outdoor Rugged Access Point (Integrated Antenna, Dual-Band)

Product Overview and Features

The Cisco AIR-AP1562I-D-K9 is a high-performance, outdoor-rated access point engineered for demanding enterprise and service-provider environments. Constructed for rugged deployment, this unit includes a sealed dual-band (2.4 GHz and 5 GHz) integrated antenna system, capable of delivering data rates up to 1.3 Gbps over three spatial streams using 802.11ac Wave 2 technology.

Built to withstand extreme outdoor conditions, the access point is designed to operate over a wide temperature range (–40 °C to +65 °C without solar loading) and can survive sustained winds of up to 100 mph, with gust tolerances reaching 165 mph . It features robust connectivity options, including a gigabit Ethernet (PoE-in), an SFP port (fiber or electrical), and a console port—enabling flexibility in network installations .

Powered via PoE+ or Cisco outdoor proprietary injectors, the AIR-AP1562I supports Cisco CleanAir™, ClientLink™, MU-MIMO, DFS, and HDX technologies for optimized RF performance in congested environments . The sealed, low-profile housing supports both centralized and mesh architectures, making it ideal for campus, stadium, industrial, and municipal wireless settings.

What’s in the Box

  • 1 × Cisco AIR-AP1562I-D-K9 access point
  • Quick-start guide and mounting instructions

Use Case Scenarios

  1. Outdoor campus and public venue Wi-Fi
  2. Industrial yard and rugged site wireless coverage
  3. Stadiums, parks, and large-scale outdoor events
  4. Municipal connectivity zones and smart city deployments
  5. Outdoor POS or drive-through systems
  6. Video surveillance access backhaul
  7. Mesh network infrastructure for hard-to-wire zones
  8. Harsh environment IoT sensor aggregators
  9. Transportation hubs and rail platforms
  10. Network extension to remote outdoor facilities

Unique Selling Propositions (USP)

  • Ruggedized housing for extreme outdoor conditions and UV/light exposure
  • Integrated 3×3 MU-MIMO and 802.11ac Wave 2 performance with up to 1.3 Gbps
  • Flexible dual-networking via PoE or SFP fiber uplink support
  • RF optimization technologies, including CleanAir, ClientLink, HDX, and DFS
Interface Specification / Port Type Notes
RJ‑45 Ethernet 10/100/1000, PoE-in Supports standard PoE+
SFP Fiber or electrical Use fiber for long-range uplinks
Console (RJ-45) Serial management port Standard CLI access
NEMA DC Power Passthru DC WARNING For powering external injectors
LED Function Color Description
Status System Health Green Operational; blinking indicates abnormal state
Link Ethernet/SFP Link Green Light on = active link; off = no link
Activity Ethernet/SFP Traffic Blinking Indicates network activity
RF Radio Status Green/Amber Green indicates both radios operational; amber indicates issues
PoE Power Input Green/Amber Green for sufficient, amber for low or failing PoE supply
Overview
The Cisco AIR-AP1562I-D-K9 is a high-performance, outdoor-rated access point engineered for demanding enterprise and service-provider environments. Constructed for rugged deployment, this unit includes a sealed dual-band (2.4 GHz and 5 GHz) integrated antenna system, capable of delivering data rates up to 1.3 Gbps over three spatial streams using 802.11ac Wave 2 technology. Built to withstand extreme outdoor conditions, the access point is designed to operate over a wide temperature range (–40 °C to +65 °C without solar loading) and can survive sustained winds of up to 100 mph, with gust tolerances reaching 165 mph . It features robust connectivity options, including a gigabit Ethernet (PoE-in), an SFP port (fiber or electrical), and a console port—enabling flexibility in network installations . Powered via PoE+ or Cisco outdoor proprietary injectors, the AIR-AP1562I supports Cisco CleanAir™, ClientLink™, MU-MIMO, DFS, and HDX technologies for optimized RF performance in congested environments . The sealed, low-profile housing supports both centralized and mesh architectures, making it ideal for campus, stadium, industrial, and municipal wireless settings.
Whats in the Box

What’s in the Box

  • 1 × Cisco AIR-AP1562I-D-K9 access point
  • Quick-start guide and mounting instructions
Use Case

Use Case Scenarios

  1. Outdoor campus and public venue Wi-Fi
  2. Industrial yard and rugged site wireless coverage
  3. Stadiums, parks, and large-scale outdoor events
  4. Municipal connectivity zones and smart city deployments
  5. Outdoor POS or drive-through systems
  6. Video surveillance access backhaul
  7. Mesh network infrastructure for hard-to-wire zones
  8. Harsh environment IoT sensor aggregators
  9. Transportation hubs and rail platforms
  10. Network extension to remote outdoor facilities
USP

Unique Selling Propositions (USP)

  • Ruggedized housing for extreme outdoor conditions and UV/light exposure
  • Integrated 3×3 MU-MIMO and 802.11ac Wave 2 performance with up to 1.3 Gbps
  • Flexible dual-networking via PoE or SFP fiber uplink support
  • RF optimization technologies, including CleanAir, ClientLink, HDX, and DFS
Port Compatibility
Interface Specification / Port Type Notes
RJ‑45 Ethernet 10/100/1000, PoE-in Supports standard PoE+
SFP Fiber or electrical Use fiber for long-range uplinks
Console (RJ-45) Serial management port Standard CLI access
NEMA DC Power Passthru DC WARNING For powering external injectors
LED Behaviour
LED Function Color Description
Status System Health Green Operational; blinking indicates abnormal state
Link Ethernet/SFP Link Green Light on = active link; off = no link
Activity Ethernet/SFP Traffic Blinking Indicates network activity
RF Radio Status Green/Amber Green indicates both radios operational; amber indicates issues
PoE Power Input Green/Amber Green for sufficient, amber for low or failing PoE supply

More About Cisco AIR-AP1562I-D-K9 – Outdoor Rugged Access Point (Integrated Antenna, Dual-Band)

Why Choose Cisco AIR-AP1562I-D-K9

  1. Built for rugged outdoor use with IP67 rating
  2. High-performance 802.11ac Wave 2 with MU-MIMO
  3. Multiple uplink choices for deployment flexibility
  4. Integrated RF optimization tech for clean performance
  5. Ideal for mesh and controller-based architectures
  6. Supports harsh environmental conditions including wind
  7. Reduced footprint with integrated antennas
  8. Easy to deploy and configure
  9. Cisco-grade reliability and support coverage
  10. Strong ROI in outdoor wireless infrastructure projects

Next Steps

  1. Verify outdoor mounting requirements for your environment
  2. Choose uplink method: PoE via RJ‑45 or fiber via SFP
  3. Plan for power—PoE+ switch or Cisco UPoE injector required
  4. Review installation guide for sealing and cable management
  5. Use IP67-rated mount kits (e.g., AIR-ACC1530 series)
  6. Include in your outdoor RF site survey for placement optimization

Pre Sales Questions

We understand that making the right purchase decision is important. Below, you’ll find answers to common pre-sales questions about this product.

What Wi-Fi standard does this AP support? +

It supports 802.11a/b/g/n/ac Wave 2 with MU-MIMO using three spatial streams

What data speeds can I expect? +

Physical data rates up to 1.3 Gbps using a single 80 MHz channel in the 5 GHz band

Does it require external antennas? +

No-the AIR-AP1562I-D includes built-in omnidirectional antennas covering both bands.

Can I use it in mesh networks? +

Yes-fully supported for mesh or centralized controller modes

What environmental conditions can it withstand? +

Operational range –40 °C to +65 °C; up to 100 mph sustained wind, 165 mph gusts

What uplink options are available? +

You can connect via PoE RJ‑45 or an SFP port for fiber or copper uplinks).

Does it support Power over Ethernet? +

Yes-compatible with standard 802.3at PoE+ and Cisco’s UPoE.

What RF technologies are supported? +

Includes CleanAir interference mitigation, ClientLink beamforming, HDX, DFS, and MU-MIMO.

Is it weatherproof? +

Yes-it’s fully IP67-sealed for outdoor exposure and comes with NEMA-rated cable glands.

What is the warranty? +

Includes a 1-year limited hardware warranty with fast replacement.
