Cisco AIR-ANT2524DW-R is a dual-band indoor antenna for 2.4 GHz and 5 GHz, designed to improve Wi-Fi coverage with easy plug-and-play installation and reliable enterprise performance.
| Specification | Details |
| Product Code | AIR‑ANT2535SDW‑R / AIR‑ANT2535SDW‑RS |
| Antenna Type | Omnidirectional dipole |
| Frequency Range | 2.4–2.5 GHz / 5.15–5.925 GHz |
| Peak Gain | 3 dBi @ 2.4 GHz; 5 dBi @ 5 GHz |
| VSWR | ≤ 2.0:1 |
| Impedance | 50 Ω |
| Polarization | Vertical |
| Beamwidth (Elevation) | 35° BOTH bands |
| Connector | RP‑TNC male |
| Diameter | 1.25 in (3.18 cm) |
| Height | 3.3 in (8.4 cm) |
| Weight | 1.7 oz (0.05 kg) |
| Operating Temp Range | –30 °C to +70 °C |
| Storage Temp Range | –40 °C to +85 °C |
| Environment | Indoor |
| Self‑ID EEPROM (RS only) | Yes, purple band on RS model |
| Product Code | AIR ANT2535SDW R / AIR ANT2535SDW RS |
|---|---|
| Antenna Type | Omnidirectional dipole |
| Supported Frequencies | 2.4–2.5 GHz / 5.15–5.925 GHz |
| Peak Gain | 3 dBi @ 2.4 GHz; 5 dBi @ 5 GHz |
| VSWR | ≤ 2.0:1 |
| Connector | RP TNC male |
| Polarization | Vertical |
| Beamwidth (Elevation) | 35° BOTH bands |
| Impedance | 50 Ω |
| Dimensions (Length x Width) | 1.25 in (3.18 cm) |
| Radome Length | 124 mm |
| Weight | 1.7 oz (0.05 kg) |
| Operating Temperature | –30 °C to +70 °C |
| Storage Temperature | –40 °C to +85 °C |
| Environment | Indoor |
| Self-ID EEPROM | Yes, purple band on RS model |
The Cisco AIR‑ANT2535SDW‑R (non‑identifying) and AIR‑ANT2535SDW‑RS (self‑identifying) are short, dual‑band omnidirectional dipole antennas designed for enterprise indoor use. Operating across 2.4 GHz and 5 GHz bands with 3 dBi and 5 dBi peak gains respectively, they are optimized for high-density Wi‑Fi environments.
Key feature of the RS model is a built-in self-identifying EEPROM allowing automatic recognition by Cisco Catalyst 9120AXE access points running IOS‑XE 17.4.1+—simplifying deployment and ensuring RF consistency. Both models connect via RP‑TNC male connectors and offer vertical polarization with a compact form factor ideal for ceiling or wall-mounted installations where discretion and installation flexibility are required. They require no external power or software configuration.
| Access Point Model | Antenna Port Type | Notes |
| Catalyst 9120AXE | RP‑TNC port | RS auto-identified, R manual only |
| Aironet 1600, 2600, 3600, 3800 | RP‑TNC port | Both R and RS function normally |
LED Behavior
Note: Indicator LEDs are on the access point, not the antenna.
| LED | Function | Color | Indicator |
| PWR | System Power Status | Green | Normal power on |
| Amber | Booting or abnormal state | ||
| ANT | Antenna Detection | Green | RS antenna auto-detected |
| Off | No detection or R antenna installed | ||
| TEMP | Temperature Status | Green | Within operational range |
| Amber | Over-temperature warning |
| Access Point Model | Antenna Port Type | Notes |
| Catalyst 9120AXE | RP‑TNC port | RS auto-identified, R manual only |
| Aironet 1600, 2600, 3600, 3800 | RP‑TNC port | Both R and RS function normally |
LED Behavior
Note: Indicator LEDs are on the access point, not the antenna.
| LED | Function | Color | Indicator |
| PWR | System Power Status | Green | Normal power on |
| Amber | Booting or abnormal state | ||
| ANT | Antenna Detection | Green | RS antenna auto-detected |
| Off | No detection or R antenna installed | ||
| TEMP | Temperature Status | Green | Within operational range |
| Amber | Over-temperature warning |
We understand that making the right purchase decision is important. Below, you’ll find answers to common pre-sales questions about this product.
RS contains EEPROM for self-ID on Catalyst 9120AXE; R does not.
Yes—but EEPROM remains unused; antenna functions normally.
Typically 8–20 m, varying with AP RF settings and obstruction.
No; hand-tighten via the knurled RP‑TNC ring.
Yes—a purple band indicates RS version compatibility.
No; only supports 2.4 GHz and 5 GHz.
Yes—they’re compatible with RP‑TNC Cisco APs.
No—RF pattern and gain remain unchanged from R model.
Typically 8–20 meters, dependent on AP power and obstacles.
Yes-identifies Port A on metas, confirming correct deployment.
Cisco Catalyst 9120AXE models running IOS-XE 17.4.1+.
